Trade Discount 25%
Surge Protection Device T1+T2 | 60kA/pole | 320V a.c. | Remote Monitoring by Legrand
Surge protection device with 60kA/pole capacity and 320V a.c. voltage—ideal for main distribution boards. Built for residential, commercial, and industrial use, with remote status monitoring for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Surge protection device of main distribution boards T1+T2 - Imax: 60kA/pole Up: 1.5kv Uc: 320V a.c. 3P with remote status monitoring - 3 module
Brand: Legrand
SKU: 412272
Alternatively Known As: Surge Protector, Surge Suppressor, SPD Device
Technical Specifications
- Surge current capacity: Imax 60kA/pole
- Voltage protection level: Up 1.5kV
- Checked operating voltage: Uc 320V a.c.
- Number of modules: 3
- Type: T1+T2 for combined protection
- Dimensions (H x L x W): 90mm x 200mm x 54mm
- Weight: 1.5 kg
Key Features
- Imax: 60kA/pole for high surge current handling
- Up: 1.5kV for low residual voltage
- Uc: 320V a.c. suitable for standard distribution voltages
- 3-module design for easy integration into distribution boards
- Remote status monitoring for enhanced safety and efficiency
Professional Installation Requirements
- Professional installation is required for optimal protection and compliance with electrical standards.
Applications
- Residential: Home electrical systems
- Commercial: Office buildings, retail spaces
- Industrial: Manufacturing plants and facilities
Standards & Compliance
- Complies with AS/NZS 1768 for lightning protection systems.
Environmental Benefits
- Minimizes equipment damage due to power surges, reducing waste and maintenance costs.
Warranty Information
5 years warranty against manufacturing defects.
Available Now
The Legrand Surge Protection Device is available now for immediate purchase. Ideal for safeguarding electrical systems in various applications.
