Switched Socket Outlet 500V 32A | IP66 | Surface Mount | Chemical Grey by Clipsal
Switched socket outlet with 500V and 32A rating, IP66 protection—ideal for industrial and commercial power supply. Built for heavy-duty use, with surface mount design for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clipsal - 56 Series, Switched Socket Outlet, 500V, 32A, 5 Round PIN, IP66, 3 Pole, Surface Mount - Chemical Grey
Brand: Clipsal
SKU: 56C532-CG
Alternatively Known As: Industrial Socket Outlet, Heavy Duty Socket, 5 Round Pin Socket
Technical Specifications
- Rated current: 32A
- Rated operational voltage: 500V AC 50Hz
- Number of poles: 5
- Device mounting: Surface
- Connections: Screw terminals for cables 4-16 mm²
- Material: ABS cover, phosphor bronze pins
- Standards: AS/NZS 3123, AS/NZS 3133
- Ambient temperature range: -25 to 75 °C
- Dimensions (H x L x W): 204mm x 108mm x 101mm
- Weight: 1.112 kg
Key Features
- IP66 rated for protection against dust and water
- Rated for 32A and 500V AC, suitable for heavy-duty applications
- Surface mount design for easy installation
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power supply for machinery and equipment
- Commercial: Small commercial applications
Standards & Compliance
- Complies with AS/NZS 60529 for IP66 rating.
Environmental Benefits
- Compliant with RoHS directives, ensuring reduced environmental impact.
Warranty Information
Standard warranty as per Clipsal's policy.
Available Now
The Clipsal 56 Series Switched Socket Outlet is available now for immediate purchase. Ideal for industrial and commercial applications.
