T-Slot Cylinder Position Sensor | 128 mm Measuring Range | Analog Output 0-10V | IP67 Rated | by SICK
The T-slot cylinder position sensor offers a 128 mm measuring range with an analog output of 0 V to 10 V, making it ideal for industrial automation and precise cylinder position measurement. Designed for factory automation systems, this sensor features an IP67 rated enclosure for dust and water protection, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: T-Slot Cylinder Position Sensor | 128 mm Measuring Range | Analog Output 0-10V | IP67 Rated | by SICK
Brand: SICK
SKU: 1048206
Alternatively Known As: T-slot cylinder position sensor, Analog cylinder sensor, SICK MPS position sensor, Cylinder displacement sensor
Technical Specifications
- Cylinder type: T-slot
- Measuring range: 128 mm
- Output function: Analog 0 V to 10 V
- Electrical wiring: DC 4-wire
- Enclosure rating: IP67
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Min. load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- EMC: According to EN 60947-5-7
- Connection type: Cable with M8 male connector, 4-pin, 0.3 m
- Cable diameter: 2.6 mm
- Cable material: PUR
- Housing material: Plastic
- Dimensions (H x L x W): 20mm x 141mm x 20mm
- Weight: 0.2 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 128 mm
- Analog output voltage from 0 V to 10 V
- DC 4-wire electrical wiring
- IP67 rated enclosure for dust and water protection
- Supply voltage range from 15 V DC to 30 V DC
- Low power consumption of 22 mA without load
- Reverse polarity and short-circuit protection
- Status indicator LED for operational feedback
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
- Cable with M8 male connector, 4-pin, 0.3 m length
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor calibration.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation systems requiring analog output sensors
- Robotics and machinery with T-slot cylinders
- Process control requiring high resolution and repeatability
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable IP67 housing reduces replacement frequency and waste
- Low power consumption contributes to energy efficiency
- Robust design minimizes downtime and resource use
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-128TSTP0S01 sensor is available for immediate purchase, ideal for industrial automation and precise cylinder position measurement applications.
