T-slot Cylinder Position Sensor MPS-128TSNUD | 128 mm Measuring Range | Analog Output 0-10V & 4-20mA | IP67 Rated | by SICK
The T-slot Cylinder Position Sensor MPS-128TSNUD offers a 128 mm measuring range with analog output options of 0 V to 10 V and 4 mA to 20 mA, making it ideal for industrial automation and precise position measurement. Designed for robust performance, it features an IP67 rated enclosure for dust and water protection, ensuring reliability in challenging environments. Perfect for factory automation, robotics, and process control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Cylinder type: T-slot
- Measuring range: 128 mm
- Housing length: 141 mm
- Output function: Analog voltage (0 V to 10 V) and current (4 mA to 20 mA)
- Electrical wiring: DC 4-wire
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 22 mA without load
- Max load resistance: ≤ 500 Ω at 24 V
- Min load resistance: ≥ 2 kΩ
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Ambient operating temperature: –20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10 to 55 Hz, 1 mm
- EMC: According to EN 60947-5-7
- Connection type: Cable, 4-wire, stripped, 10 m PUR cable, axial outlet
- Material: Plastic housing, PUR cable
- Dimensions (H x L x W): 20mm x 141mm x 20mm
- Weight: 0.2 kg
Key Features
- T-slot cylinder type compatible with various cylinder profiles
- Measuring range of 128 mm
- Analog output with voltage (0 V to 10 V) and current (4 mA to 20 mA) options
- IP67 rated enclosure for dust and water protection
- Supply voltage range from 15 V DC to 30 V DC
- Reverse polarity and short-circuit protection
- Status indicator LED for operational feedback
- High resolution of 0.03% FSR and repeat accuracy of 0.06% FSR
- Shock and vibration resistant (30 g, 11 ms / 10 to 55 Hz, 1 mm)
- Cable connection with 10 m PUR cable, axial outlet
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and compliance with safety standards.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation systems
- Robotics and mechanical engineering
- Process control requiring analog position feedback
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable IP67 housing reduces environmental damage and extends product life
- Low power consumption of 22 mA reduces energy usage
- Robust design minimizes waste through long operational life
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-128TSNUD Analog T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and precise position measurement applications.
