T-slot Cylinder Position Sensor | 192 mm Measuring Range | IO-Link V1.1 | IP67 Rated | by SICK
The T-slot Cylinder Position Sensor is designed for precise position measurement in industrial automation, featuring a 192 mm measuring range and high resolution of 0.03% FSR. With an IP67 rated enclosure, it ensures reliable performance in harsh environments, making it ideal for factory automation and robust sensing applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Cylinder type: T-slot
- Measuring range: 192 mm
- Housing length: 205 mm
- Output function: IO-Link V1.1
- Electrical wiring: DC 4-wire
- Enclosure rating: IP67
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 25 mA without load
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection: Yes
- Status indicator LED: Yes
- Ambient operating temperature: -20°C to +70°C
- Shock and vibration resistance: 30 g, 11 ms / 10-55 Hz, 1 mm
- Connection type: Cable with M12 male connector, 4-pin, 0.3 m
- Cable specifications: PUR, 0.08 mm² conductor cross section, 2.6 mm diameter
- Bending radius: Fixed installation > 5x cable diameter, flexible use > 10x cable diameter
- Material: Plastic housing
- Dimensions (H x L x W): 20mm x 205mm x 20mm
- Weight: 0.3 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 192 mm with high resolution of 0.03% FSR
- IO-Link V1.1 communication interface with COM2 and 2.3 ms cycle time
- IP67 rated enclosure for protection against dust and water
- Electrical wiring: DC 4-wire with reverse polarity and short-circuit protection
- Status indicator LED and teach-in functionality for easy setup
- Operating temperature range from -20°C to +70°C
- Shock and vibration resistant (30 g, 11 ms / 10-55 Hz, 1 mm)
- Cable with M12 male connector, 4-pin, 0.3 m length
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper setup and IO-Link integration.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation requiring robust and accurate sensing
- Use in environments needing IP67 rated sensors with IO-Link communication
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient sensor design reduces power consumption
- Durable IP67 housing extends product life and reduces waste
- Supports predictive maintenance via IO-Link to minimize downtime and resource use
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK MPS-192TLTQ0 T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and factory applications requiring precise position sensing.
