T-slot Cylinder Position Sensor MPS-160TLTQ0 | IO-Link Output | IP67 Rated | 160 mm Measuring Range | by SICK
The T-slot Cylinder Position Sensor MPS-160TLTQ0 is designed for precise linear position measurement in industrial automation. With an IO-Link output function and a robust IP67 rating, it ensures reliable performance in demanding environments. Ideal for factory automation, this sensor features a measuring range of 160 mm and is compatible with various cylinder types, making it a versatile choice for your automation needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 15 V DC to 30 V DC
- Power consumption: 25 mA without load
- Protection class: III
- Time delay before availability: 1.5 s
- Magnetic field sensitivity: 4 mT to 30 mT
- Resolution: 0.03% FSR (max. ≥ 0.05 mm)
- Linearity error: 0.3 mm
- Repeat accuracy: 0.06% FSR (≥ 0.1 mm)
- Sampling rate: 1 ms
- Reverse polarity and short-circuit protection included
- Status indicator LED present
- Ambient operating temperature: -20 °C to +70 °C
- Shock and vibration resistance: 30 g, 11 ms / 10 ... 55 Hz, 1 mm
- EMC compliant according to EN 60947-5-7
- Communication interface: IO-Link V1.1, COM2, cycle time 2.3 ms
- Process data length: 16 Bit
- Process data structure: Bit 0 ... 15 = position (in 1 mm/128)
- Cable: PUR, 0.3 m length, M12 male connector, 4-pin
- Dimensions (H x L x W): 30mm x 173mm x 30mm
- Weight: 0.5 kg
Key Features
- T-slot cylinder type compatible with round body, profile, tie-rod, dovetail groove cylinders and SMC rails
- Measuring range of 160 mm
- IO-Link output function with standard functions and teach-in capability
- Electrical wiring: DC 4-wire with reverse polarity and short-circuit protection
- Enclosure rating IP67 for dust and water protection
- Status indicator LED for operational feedback
- Shock and vibration resistant (30 g, 11 ms / 10 ... 55 Hz, 1 mm)
- Operating temperature range from -20 °C to +70 °C
- Cable with M12 male connector, 4-pin, 0.3 m length, PUR material
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure correct wiring, configuration, and integration with IO-Link systems.
Applications
- Industrial automation for precise cylinder position measurement
- Factory automation requiring robust and accurate linear position sensing
- Use in environments needing IP67 rated sensors with IO-Link communication
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation with low power consumption (25 mA without load)
- Durable design reduces replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK MPS-160TLTQ0 T-slot Cylinder Position Sensor is available for immediate purchase, ideal for industrial automation and factory applications requiring precise linear position measurement.
