Temprite High Side Float 3/4 Rotalock x 1/4 FNPT | 4480 kPa SWP | Efficient Oil Separation | by Aspen Pumps
The Temprite High Side Float 3/4 Rotalock x 1/4 FNPT is designed for efficient oil level control in HVAC and refrigeration systems. With a safe working pressure of 4480 kPa and advanced Temprite technology, it ensures optimal oil separation and performance down to 20% of maximum flow. Ideal for industrial applications, this coalescent oil separator is compliant with Australian standards, making it a reliable choice for professionals.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Temprite High Side Float 3/4 Rotalock x 1/4 FNPT | 4480 kPa SWP | Efficient Oil Separation | by Aspen Pumps
Brand: Aspen Pumps
SKU: 308-3358717
Alternatively Known As: Temprite Oil Level Controller, High Side Float Pressure Vessel, Coalescent Oil Separator
Technical Specifications
- SWP (Safe Working Pressure): 4480 kPa
- Connection Type: 3/4 inch Rotalock x 1/4 inch FNPT
- Technology: Temprite coalescent oil separator
- Performance: Maintains efficiency down to 20% of maximum flow
- Compliance: Manufactured in accordance with Australian standards
- Dimensions (H x L x W): 300mm x 150mm x 150mm
- Weight: 1.5 kg
Key Features
- SWP: 4480 kPa
- Temprite Technology for efficient oil separation
- Coalescent oil separators maintain efficiency down to 20% of maximum flow
- Not velocity dependent for consistent performance
Professional Installation Requirements
- Installation should be performed by a qualified HVAC technician or licensed plumber to ensure compliance with safety and operational standards.
Applications
- HVAC systems for oil level control
- Refrigeration and air conditioning systems
- Industrial pressure vessel applications requiring oil separation
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Manufactured in accordance with Australian standards and registered with Worksafe where applicable
Environmental Benefits
- Energy-efficient oil separation reduces system energy consumption
- Improves system longevity and reduces waste through effective oil management
Warranty Information
Standard manufacturer warranty applies; please refer to Aspen Pumps for specific terms.
Available Now
The Temprite High Side Float 3/4 Rotalock x 1/4 FNPT pressure vessel is available for immediate purchase, ideal for HVAC and refrigeration system oil level control applications.
