Terminal Block 10A 12 Way | 415V Voltage Rating | Flame-Retardant Polyamide | Nickel-Plated Brass by Cabac

BRAND: CABAC
SKU: TB10/12WAY
$7.70 List price: $9.30
+ −
30 Days Return Delivery Options
Cabac Terminal Block 10A 12 Way provides secure and reliable electrical connections with flame-retardant Polyamide 66 construction and nickel-plated brass terminals, ideal for control panels and enclosures.

Product Name/Title: Terminal Block 10A 12 Way

Brand: Cabac

SKU: TB10/12WAY

Alternatively Known As: Electrical Terminal Block Strip, 12 Way Terminal Block, Wire Connector Block, Terminal Strip 10A, Electrical Connector Terminal

Technical Specifications
  • Voltage Rating: 415V
  • Maximum Operating Temperature: 105°C
  • Material: Polyamide 66 (flame-retardant)
  • Screw Type: Chrome-plated steel
  • Terminal Material: Nickel-plated brass with wire protector plate
  • Configuration: 12-way strips (modifiable as required)
  • Amp Rating: 10A
  • Max Conductor Size: 4.0 mm
  • Dimensions (H x L x W): 20mm x 15mm x 120mm
  • Weight: 0.1 kg
Key Features
  • Manufactured from flame-retardant Polyamide 66 for durability and electrical insulation
  • Nickel-plated brass terminals with wire protector plate for enhanced conductivity and mechanical integrity
  • Chrome-plated steel screws ensure secure wire clamping
  • Supplied in 12-way strips, easily cut to required lengths
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and optimal performance.
Applications
  • General electrical wiring and termination
  • Industrial control panels and distribution boards
  • Equipment wiring and power distribution
  • Low to medium voltage electrical connections
  • Electrical enclosures and junction boxes
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Flame-retardant and durable materials reduce the need for frequent replacements, minimizing waste
  • Nickel-plated terminals resist corrosion, extending product lifespan
Warranty Information

Standard manufacturer warranty applies. Please refer to Cabac warranty policy for details.

Available Now

The Cabac Terminal Block 10A 12 Way is available for immediate purchase, ideal for electrical wiring and control panel applications.
