Terminal Block Relay with Socket | 48V DC | SPDT Configuration | 6A Current Rating | by Allen-Bradley
The Terminal Block Relay with Socket from Allen-Bradley operates at 48V DC and features a secure screw clamp terminal design, making it ideal for industrial control systems and automation equipment. With a 6A current rating and built-in coil surge protection, this relay ensures reliable performance and longevity, perfect for electrical panel installations and signal switching applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Relay Type: Terminal block relay with socket
- Terminals: Screw clamp
- Retainer Clip: Built-in
- LED Indicator: Standard
- Coil Voltage: 48 V DC
- Relay Current Rating: 6 A
- Contact Configuration: SPDT
- Coil Surge Protection: Included
- Module: Replaceable relay module
- Dimensions (H x L x W): 60mm x 50mm x 20mm
- Weight: 0.1 kg
Key Features
- Terminal block relay with socket
- Screw clamp terminals for secure connections
- Built-in retainer clip for stability
- Standard LED indicator
- Coil surge protection
- Replaceable relay module
- 6 A relay current rating
- SPDT (Single Pole Double Throw) configuration
- Operates at 48 V DC
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Industrial control systems
- Automation equipment
- Electrical panel installations
- Signal switching and control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Coil surge protection extends relay lifespan, reducing electronic waste
- Replaceable relay module minimizes full unit replacement, promoting sustainability
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 700HLT1Z48 Terminal Block Relay with Socket is available for immediate purchase, ideal for industrial and automation control applications.
