Terminal Block Relay with Socket | SPDT Configuration | 24V DC Coil | LED Indicator | by Allen-Bradley
The Terminal Block Relay with Socket from Allen-Bradley is designed for industrial control systems, featuring a reliable SPDT configuration and a 24V DC coil voltage. With screw clamp terminals for secure wiring and a built-in retainer clip, this relay ensures safe and efficient operation in hazardous locations. The standard LED indicator provides real-time status monitoring, making it an essential component for automation equipment.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Relay Type: Terminal Block Relay with Socket
- Terminals: Screw clamp
- Retainer Clip: Built-in
- LED Indicator: Standard
- Coil Surge Protection: Yes
- Relay Current Rating: 6 A
- Contact Configuration: SPDT
- Coil Voltage: 24 V DC
- Certification: Hazardous location certified
- Dimensions (H x L x W): 80mm x 60mm x 30mm
- Weight: 0.2 kg
Key Features
- Screw clamp terminals for secure wiring
- Built-in retainer clip for reliable mounting
- Standard LED indicator for status monitoring
- Coil surge protection to enhance relay longevity
- Replaceable relay module for easy maintenance
- 6 A relay current rating
- SPDT (Single Pole Double Throw) contact configuration
- 24 V DC coil voltage
Professional Installation Requirements
- Installation by a qualified electrician is required to ensure compliance with hazardous location standards and safety.
Applications
- Industrial control systems
- Automation equipment
- Hazardous location electrical installations
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Coil surge protection extends product life, reducing waste
- Replaceable relay module minimizes full unit replacement
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 700HLT1Z24EX Terminal Block Relay with Socket is available for immediate purchase, ideal for industrial and hazardous location electrical control applications.
