Home/Electrical/Switchgear/Overloads/Thermal Overloads/Thermal Overload Relay 12-18A | 690VAC | 1NO+1NC | Class 10A by Clipsal

Trade Discount 33%

TeSys LR.D, Thermal overload relay, TeSys Deca, 690VAC, 12 to 18A, 1NO+1NC, class 10A, screw clamp

Thermal Overload Relay 12-18A | 690VAC | 1NO+1NC | Class 10A by Clipsal

BRAND: Clipsal

SKU: LRD21

$66.50 List price: $99.70

+ −

30 Days Return Delivery Options

Thermal overload relay with 12-18A adjustable range and 690VAC rating—ideal for motor protection in industrial applications. Built for reliability, with 1NO+1NC contacts and class 10A rating.

Description
Attachments

Product Name/Title: TeSys LR.D, Thermal overload relay, TeSys Deca, 690VAC, 12 to 18A, 1NO+1NC, class 10A, screw clamp

Brand: Clipsal

SKU: LRD21

Alternatively Known As: Thermal overload relay, TeSys Deca relay, Motor protection relay

Technical Specifications

Rated insulation voltage: 600V (CSA), 690V (IEC)
Control circuit: screw clamp terminals for flexible and solid cables
Rated impulse withstand voltage: 6 kV
Mechanical robustness: vibrations up to 6 Gn, shocks up to 15 Gn
Dielectric strength: 1.89 kV at 50 Hz
Dimensions (H x L x W): 66mm x 70mm x 45mm
Weight: 0.124 kg

Key Features

Differential thermal overload relay with class 10A rating.
Rated operational voltage of 690 VAC.
Adjustable thermal protection range from 12 to 18A.
Includes 1NO + 1NC auxiliary contacts.

Professional Installation Requirements

Professional installation is recommended for optimal performance and safety.

Applications

Motor protection in industrial applications
Compatible with various TeSys contactors

Standards & Compliance

Complies with IEC 60947-4-1 for safety and performance.

Environmental Benefits

Green Premium product status.

Warranty Information

18 months warranty against manufacturing defects.

Available Now

The TeSys LR.D Thermal Overload Relay is available now for immediate purchase. Ideal for motor protection in industrial settings.

LRD21 (LRD21, 244 Kb) [Download]
