Thermal Overload Relay 17-25A | Fits LC1D80-D95 | Manual & Automatic Reset | Phase Failure Sensitivity | @Pack of 1 | by Clipsal
The Thermal Overload Relay 17-25A is designed for reliable motor protection, fitting perfectly with LC1D80-D95 contactors. With adjustable current settings and both manual and automatic reset options, it ensures optimal performance in industrial automation and control panels. Ideal for HVAC systems, pumps, and conveyor systems, this relay enhances energy efficiency and prevents motor damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thermal Overload Relay 17-25A | Fits LC1D80-D95 | Manual & Automatic Reset | Phase Failure Sensitivity | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLRD3322
Alternatively Known As: thermal overload relay, motor protection relay, overload protector, LC1D80-D95 overload, SCHLRD3322 relay
Technical Specifications
- Current adjustment range: 17-25A
- Suitable for LC1D80-D95 contactors
- Trip class: 10A
- Manual/automatic reset
- Phase failure sensitivity
- Test and stop functions
- Mounting: Direct on contactor
- Dimensions (H x L x W): 100mm x 120mm x 70mm
- Weight: 0.35 kg
Key Features
- Adjustable current range: 17-25A
- Direct fit for LC1D80-D95 contactors
- Manual and automatic reset options
- Phase failure sensitivity
- Trip class 10A for fast motor protection
- Test and stop functions for easy maintenance
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure correct integration with motor starters and compliance with safety standards.
Applications
- Motor protection in industrial automation
- Control panels for machinery
- HVAC systems
- Pumps and compressors
- Conveyor systems
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Prevents motor damage, reducing equipment waste
- Enhances energy efficiency by protecting against overloads
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal SCHLRD3322 Thermal Overload Relay (17-25A) is available for immediate purchase. Ideal for industrial motor protection and automation panels.
