Thermal Overload Relay 9-13A | 690VAC | IP20 Rated | EverLink BTR by Clipsal
Thermal overload relay with 9-13A adjustment range and 690VAC rating—ideal for industrial motor protection. Built for reliability, with IP20 protection and EverLink BTR screw connectors.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operational voltage: 690 V AC, 0...400 Hz
- Control type: red push-button for stop, blue push-button for reset
- Connections: screw clamp terminals for control circuit, EverLink BTR screw connectors for power circuit
- Thermal overload class: class 10A
- Rated insulation voltage: 600 V conforming to CSA and UL
- Rated impulse withstand voltage: 6 kV
- Mechanical robustness: shocks 15 Gn for 11 ms, vibrations 4 Gn
- Dielectric strength: 1.89 kV at 50 Hz
- Dimensions (H x L x W): 70mm x 123mm x 55mm
- Weight: 0.375 kg
Key Features
- Differential thermal overload relay with a thermal protection adjustment range of 9 to 13A.
- IP20 rated for protection against solid objects.
- EverLink BTR screw connectors for reliable power circuit connections.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Motor protection in industrial applications
- Compatible with LC1D40, LC1D50, and LC1D65 contactors
Standards & Compliance
- Complies with EN/IEC 60947-4-1 and other relevant standards.
Environmental Benefits
- Conforms to environmental standards and regulations.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The TeSys LR.D Thermal Overload Relay is available now for immediate purchase. Ideal for industrial motor protection applications.
