Thermal Overload Relay RTX3 400 | 100-160A Adjustable Range | Class 10A Protection | @EA of 1 | by Legrand
The Thermal Overload Relay RTX3 400 is designed for reliable motor protection with an adjustable current range of 100-160A and Class 10A thermal release. Ideal for industrial motor control applications, it features screw terminals for easy installation and includes a trip indicator and reset options for enhanced safety and convenience.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thermal Overload Relay RTX3 400 | 100-160A Adjustable Range | Class 10A Protection | @EA of 1 | by Legrand
Brand: Legrand
SKU: 416787
Alternatively Known As: Thermal Overload Relay, Motor Protection Relay, RTX3 Thermal Relay, Legrand Motor Relay
Technical Specifications
- Adjustable current range: 100-160 A
- Max rated operation voltage (Ue): 690 V
- Mounting method: Direct attachment
- Type of electrical connection: Screw connection
- Auxiliary contacts: 1 normally open (NO), 1 normally closed (NC)
- Release class: Class 10
- Screw terminals capacity: Power circuit up to 70mm², Auxiliary circuit up to 1mm²
- Reset button selector: Automatic or manual reset
- Includes trip indicator and Stop/Test button
- Dimensions (H x L x W): 110mm x 120mm x 70mm
- Weight: 1.2 kg
Key Features
- Adjustable current range from 100 to 160 A
- Class 10 thermal release for motor protection
- 1NO + 1NC auxiliary contacts (0.75A / 240V AC)
- Screw terminals with capacity up to 70mm² for power circuit
- Reset button selector with automatic or manual reset options
- Trip indicator and Stop/Test button for easy operation
- Direct attachment mounting method
- Designed for tertiary and industrial installations
Professional Installation Requirements
- Professional installation by a qualified electrician is required to ensure correct setup and compliance with safety standards.
Applications
- Industrial motor control and protection
- Tertiary and industrial electrical installations
- Direct association with CTX3 contactors
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Protects motors from overheating, reducing energy waste and extending equipment life
- Durable design reduces replacement frequency and electronic waste
Warranty Information
3 years warranty against manufacturing defects.
Available Now
Legrand Thermal Overload Relay RTX3 400 100-160A Class 10A Differential is available for immediate purchase, ideal for industrial motor control and protection applications.
