Thermal Overload Relay RTX3 Mini 40 | 12-18A Adjustable Range | Class 10A | @EA of 1 | by Legrand
The Thermal Overload Relay RTX3 Mini 40 is designed for effective motor protection, featuring an adjustable current range of 12-18A and a maximum rated operation voltage of 690V. Ideal for industrial and tertiary applications, this relay ensures safety and compliance while extending motor lifespan and reducing energy waste.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thermal Overload Relay RTX3 Mini 40 | 12-18A Adjustable Range | Class 10A | @EA of 1 | by Legrand
Brand: Legrand
SKU: 417093
Alternatively Known As: Thermal Overload Relay, Motor Protection Relay, RTX3 Mini Relay, Legrand Motor Relay
Technical Specifications
- Adjustable current range: 12-16 A
- Max. rated operation voltage (Ue): 690 V
- Number of auxiliary contacts normally closed (NC): 1
- Number of auxiliary contacts normally open (NO): 1
- Number of auxiliary contacts change-over: 0
- Type of electrical connection: Screw connection
- Mounting method: Direct attachment
- Release class: CLASS 10
- Auxiliary contact rating: 0.75A / 240V AC - 15
- Dimensions (H x L x W): 80mm x 70mm x 45mm
- Weight: 0.2 kg
Key Features
- 1NO + 1NC auxiliary contact (0.75A / 240V AC - 15)
- Screw terminals capacity: Power 1.25mm² to 2mm² / Auxiliary circuit 1mm²
- Reset button selector with automatic or manual reset options
- Trip indicator and Stop/Test button
- Direct association to CTX3 mini contactor
- Adjustable current range from 12 to 16 A
- Maximum rated operation voltage of 690 V
- Mounting method: Direct attachment
- Screw connection for main circuit electrical connection
- Release class: CLASS 10
Professional Installation Requirements
- Installation should be performed by a qualified electrician familiar with motor control and protection devices to ensure safety and compliance.
Applications
- Protection of 3-phase motors up to 7.5kW / 415V in industrial and tertiary installations
- Motor control and protection in manufacturing plants and commercial facilities
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Protects motors from overload, reducing energy waste and extending motor lifespan
- Helps prevent equipment damage, minimizing electronic waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Legrand warranty policy for details.
Available Now
The Legrand Thermal Overload Relay RTX3 Mini 40 12-18A Class 10A Differential is available for immediate purchase, ideal for industrial and tertiary motor protection applications.
