Thread Rolling Screw M2.5x10 | Taptite 2000 | Flat Head & TX8 Drive | @Pack of 50 | by Wurth
The GEFU thread rolling screw M2.5x10 is designed for high-load mechanical fastening, featuring a flat head and TX8 hexalobular drive. Ideal for assembly in cast blind holes and sheet metal parts, this self-tapping screw eliminates the need for thread cutting, reducing material waste while ensuring a strong, play-free connection. Perfect for professionals seeking reliable performance in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thread Rolling Screw M2.5x10 | Taptite 2000 | Flat Head & TX8 Drive | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712510
Alternatively Known As: Thread rolling screw, Taptite 2000 screw, Self-tapping screw M2.5, Hexalobular drive screw TX8, Flat head thread forming screw
Technical Specifications
- Thread type x nominal diameter: M2.5
- Length: 10 mm
- Head diameter: 5 mm
- Head height: 2.1 mm
- Head type: Flat head
- Material: Steel, case-hardened
- Surface: Zinc plated with blue passivation (A2K) and slide coating
- Thread type: Metric thread
- Internal drive: TX8 (hexalobular)
- Guideline hole diameter: 2.3 mm
- Standards: DIN 7500-1
- RoHS-compliant: Yes
- Dimensions (H x L x W): 2.1mm x 10mm x 5mm
- Weight: 0.01 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened zinc-plated steel with blue passivation (A2K) and slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form a nut thread without interrupting material structure
- Low rolling torques with greater thread flank overlap
- High clamping force and load-bearing capacity
- Play-free and self-locking thread seating
- Protection against loosening
- Thread corresponds to standard metric thread allowing replacement with metric screws
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure correct torque and thread forming without damaging materials.
Applications
- Assembly in cast blind holes
- Sheet metal parts including drilled, lasered, and punched
- Mechanical fastening requiring self-tapping screws with high load-bearing capacity
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates need for thread cutting, reducing material waste
- RoHS-compliant, free from hazardous substances
Warranty Information
Warranty against manufacturing defects as per Wurth standard terms and conditions.
Available Now
The Wurth GEFU thread rolling screw M2.5x10 with flat head and TX8 drive is available for immediate purchase. Ideal for mechanical assembly and metal fastening applications.
