Thread Rolling Screw Taptite 2000 | Flat Head & Hexalobular Drive | Zinc Plated A2K | @Pack of 50 | by Wurth
The GEFU thread rolling screw with Taptite 2000 thread is designed for high-performance fastening in metal applications. Featuring a flat head and hexalobular drive, this screw ensures a secure fit without interrupting material structure. Ideal for professionals in mechanical fastening, it offers high load-bearing capacity and self-locking thread seating, making it perfect for various sheet metal parts.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thread Rolling Screw Taptite 2000 | Flat Head & Hexalobular Drive | Zinc Plated A2K | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712506
Alternatively Known As: Thread rolling screw, Taptite screw, Self-tapping screw, Hexalobular drive screw, Flat head thread forming screw
Technical Specifications
- Thread type x nominal diameter: M2.5
- Length: 6 mm
- Head diameter: 5 mm
- Head height: 2.1 mm
- Head type: Flat head
- Material: Steel, case-hardened
- Surface: Zinc plated with blue passivation (A2K)
- Thread type: Metric thread
- Internal drive: TX8 (hexalobular)
- Guideline values for hole diameters: 2.3 mm
- Standards: DIN 7500-1
- RoHS-compliant: Yes
- Dimensions (H x L x W): 2.1mm x 6mm x 5mm
- Weight: 0.01 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened zinc-plated steel with blue passivation (A2K) and slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form a nut thread without interrupting material structure
- Non-cutting thread formation displaces and strain-hardens material
- Low rolling torques with greater thread flank overlap
- Trilobular core diameter shape combined with radius profile of thread flanks
- High clamping force and load-bearing capacity
- Protection against loss and reduced likelihood of screw loosening
- Play-free and self-locking thread seating
- Formed thread corresponds to standard metric thread
- RoHS-compliant
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure proper thread forming and fastening performance.
Applications
- Used for fastening in cast blind holes, rim holes, drilled, lasered, and punched sheet metal parts
- Ideal for mechanical and functional fastening requiring high load-bearing capacity and self-locking thread seating
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates need for thread cutting, reducing manufacturing waste
- RoHS-compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to Wurth warranty policy for details.
Available Now
Available for immediate purchase, ideal for mechanical fastening in metal fabrication and assembly applications.
