Thread Rolling Screw Taptite 2000 | M2.5 Flat Head | TX8 Hexalobular Drive | Zinc Plated | @Pack of 50 | by Wurth
The GEFU thread rolling screw with Taptite 2000 thread is designed for efficient fastening in metal applications. Featuring a flat head and TX8 hexalobular drive, this self-tapping screw eliminates the need for thread cutting, making it ideal for assembly in cast blind holes and sheet metal parts. Made from case-hardened steel with zinc plating, it ensures high clamping force and load-bearing capacity, perfect for professionals in mechanical fastening.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thread Rolling Screw Taptite 2000 | M2.5 Flat Head | TX8 Hexalobular Drive | Zinc Plated | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712516
Alternatively Known As: Thread rolling screw, Taptite 2000 screw, Self-tapping screw M2.5, Hexalobular drive screw, TX8 screw, Zinc plated flat head screw
Technical Specifications
- Thread type x nominal diameter: M2.5
- Length: 16 mm
- Head diameter: 5 mm
- Head height: 2.1 mm
- Head type: Flat head
- Material: Steel, case-hardened
- Surface: Zinc plated with blue passivation (A2K)
- Thread type: Metric thread
- Internal drive: TX8 hexalobular
- Guideline hole diameter: 2.3 mm
- Standard: DIN 7500-1
- RoHS compliant: Yes
- Dimensions (H x L x W): 2.1mm x 16mm x 5mm
- Weight: 0.01 kg
Key Features
- Case-hardened steel with zinc plating and blue passivation (A2K) with slide coating
- Flat head with hexalobular (TX8) drive
- Self-tapping thread rolling screw forming nut thread without cutting
- Low rolling torque with high thread flank overlap
- High clamping force and load-bearing capacity
- Play-free and self-locking thread seating
- Complies with DIN 7500-1 and ISO 14583 head dimensions
- RoHS compliant
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure correct torque and thread formation.
Applications
- Assembly of cast blind holes
- Sheet metal parts fastening
- Rim holes and drilled, lasered, punched metal parts
- Mechanical and functional fastening requiring self-tapping screws
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates need for thread cutting, reducing material waste
- RoHS compliant, free from hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty policy for details.
Available Now
Available for immediate purchase, ideal for mechanical fastening in metal fabrication and assembly applications.
