Thread Rolling Screw Taptite 2000 | M4x30 | Hexagon Head with Collar | Zinc Plated | @Pack of 100 | by Wurth
The GEFU thread rolling screw with Taptite 2000 thread is designed for high-performance fastening in industrial applications. With a self-tapping design and a robust M4x30 size, it ensures a secure fit without compromising material integrity. Made from case-hardened steel and zinc plated for corrosion resistance, this screw is ideal for mechanical assembly and offers high load-bearing capacity, making it perfect for demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Thread Rolling Screw Taptite 2000 | M4x30 | Hexagon Head with Collar | Zinc Plated | @Pack of 100 | by Wurth
Brand: Wurth
SKU: 20973430
Alternatively Known As: Taptite 2000 screw, thread rolling screw, self-tapping hex screw, DIN 7500-1 screw, hexagon head screw with collar
Technical Specifications
- Thread type x nominal diameter: M4
- Length: 30 mm
- Collar diameter: 8.45 mm
- Head height: 4 mm
- External drive: WS7 hexagon
- Guideline hole diameter: 3.7 mm
- Material: Steel, case-hardened
- Surface: Zinc plated
- RoHS-compliant: Yes
- Head type: Hexagon head
- Drive type: Hexagon
- Thread type: Metric thread
- Collar/flange: Yes
- Dimensions (H x L x W): 4mm x 30mm x 8.45mm
- Weight: 0.02 kg
Key Features
- Self-tapping screws form a nut thread without interrupting material structure
- Case-hardened steel with zinc plating for corrosion resistance
- TRILOBULAR core shape combined with radius profile for low rolling torque and high thread flank overlap
- High clamping force and load-bearing capacity due to strain-hardened counter thread
- Play-free and self-locking thread seating reduces likelihood of screw loosening
- Complies with DIN 7500-1 standard
Professional Installation Requirements
- Installation by a qualified technician or professional is recommended to ensure proper thread formation and torque application.
Applications
- Used for fastening in cast blind holes, rim holes, drilled, lasered, and punched sheet metal parts
- Ideal for applications requiring high load-bearing capacity and self-locking thread seating
- Suitable for industrial and mechanical assembly where strain-hardened threads are beneficial
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing replacement frequency
Warranty Information
Warranty as per Wurth standard terms and conditions.
Available Now
The Wurth GEFU Thread Rolling Screw with Taptite 2000 Hexagon Head M4x30 is available for immediate purchase, ideal for industrial and mechanical fastening applications.
