Three-Phase Energy Meter | LCD Display | Modbus Protocol | DIN Rail by NHP
Three-phase energy meter with LCD display and Modbus protocol—ideal for industrial, commercial, and residential energy monitoring. Built for easy integration, with DIN rail mounting for convenient installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Carlo Gavazzi EM270 Energy Meter Quick Fit CT Connect with RS485 Digital I/O
Brand: NHP
SKU: EM27072DMV53X2SX
Alternatively Known As: EM270 Energy Meter, Carlo Gavazzi Energy Meter, Multifunction Energy Meter
Technical Specifications
- Nominal Voltage (L-L): 415-277 V
- Nominal Voltage (N-L): 160-240 V
- Frequency: 45-65 Hz
- Sampling Frequency: 1900 Hz
- Supply Voltage (AC 50 Hz): 40-460 V
- Pulse Rate: 100-1000 Imp/kWh (kvarh)
- Refresh Time: 1 s
- Pole Type: Three conductor/four conductor
- Type of Display: LCD
- Pulse Output: Optic
- Supporting Protocol for Modbus: Yes
- Terminal Type: Screw
- Mounting Method: DIN rail
- Material Housing: Nylon
- With Lock Code: Yes
- Degree of Protection (IP): IP50
- Operating Temperature: -25-55 °C
- Storage Temperature: -30-70 °C
- Dimensions (H x L x W): 72mm x 65mm x 72mm
- Weight: 0.4 kg
Key Features
- Three-phase energy meter with LCD display.
- Supports Modbus protocol for easy integration.
- DIN rail mounting for convenient installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Energy monitoring in manufacturing facilities
- Commercial: Energy management in office buildings
- Residential: Monitoring energy consumption in homes
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Helps in monitoring and reducing energy consumption, leading to lower carbon footprint.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Carlo Gavazzi EM270 Energy Meter Quick Fit CT Connect with RS485 Digital I/O is available now for immediate purchase. Ideal for industrial, commercial, and residential energy monitoring.
