Through-Beam Photoelectric Sensor WSE4SP-21312100ZZZ | 12m Sensing Range | IP66/IP67 Rated | Fast Response Time | by SICK
The WSE4SP-21312100ZZZ through-beam photoelectric sensor is designed for industrial automation, featuring a sensing range of up to 12 meters and a PinPoint LED light source with a 635 nm wavelength. With an impressive LED service life of 100,000 hours and IP66/IP67 protection, it’s perfect for detecting objects in harsh environments, ensuring reliable performance and minimal maintenance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing range: 0 m to 12 m (recommended 0 m to 9 m)
- Light source: PinPoint LED, visible red light, 635 nm wavelength
- LED service life: 100,000 hours at 25°C
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA without load at 24 V
- Output type: Push-pull PNP/NPN light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1,000 Hz
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature: -40°C to +60°C
- Storage temperature: -40°C to +75°C
- Housing material: Plastic VISTAL®
- Front screen material: Plastic PMMA
- Connection: M8, 3-pin connector
- Dimensions (H x L x W): 41.9mm x 18.6mm x 12.1mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with sensing range up to 12 m
- PinPoint LED visible red light with 635 nm wavelength
- High LED service life of 100,000 hours at 25°C
- Slim plastic VISTAL® housing with PMMA front screen
- IP66 and IP67 rated for dust and water protection
- Fast response time of ≤ 500 µs and switching frequency of 1,000 Hz
- LED indicators for alignment aid, power, and object detection status
- Reverse polarity, overcurrent, and short-circuit protected outputs
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper alignment and electrical connection according to safety standards.
Applications
- Industrial automation for object detection
- Detection of poorly remitting and tilted objects
- Use in harsh environments requiring IP66/IP67 protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long LED service life reduces waste and replacement frequency
- Energy-efficient operation with low current consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WSE4SP-21312100ZZZ through-beam photoelectric sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
