Through-Beam Photoelectric Sensor WSE12-3P2431T01 | 15m Sensing Range | IP66/IP67/IP69K Rated | Fast Response Time | by SICK
The WSE12-3P2431T01 Through-beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 15 meters and a fast response time of ≤ 330 µs. With a durable metal housing and IP66/IP67/IP69K ratings, it's perfect for hygienic and washdown environments, ensuring reliable object detection in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Through-Beam Photoelectric Sensor WSE12-3P2431T01 | 15m Sensing Range | IP66/IP67/IP69K Rated | Fast Response Time | by SICK
Brand: SICK
SKU: 1041461
Alternatively Known As: Through-beam photoelectric sensor, SICK photoelectric sensor, WSE12 sensor, industrial object sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 15 m (max 20 m)
- Light source: LED, visible red light, wavelength 640 nm
- Light spot size at 15 m: Ø 220 mm
- Adjustment: Potentiometer, 5 turns
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Current consumption sender: ≤ 30 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Digital output: PNP, light/dark switching, max output current ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Housing: Metal zinc diecast with PTFE coating
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: –40 °C to +60 °C
- Storage temperature: –40 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Through-beam photoelectric sensor with visible red LED light
- Sensing range up to 15 m (max 20 m)
- Teflon coated housing for hygienic and washdown environments
- Metal zinc diecast housing with PTFE coating
- IP66, IP67, and IP69K rated for robust protection
- Fast response time of ≤ 330 µs and switching frequency of 1,500 Hz
- Light/dark switching mode with PNP digital output
- Operating temperature range from –40 °C to +60 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Hygienic and washdown zones
- Safety and monitoring in manufacturing processes
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- Energy-efficient LED light source minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WSE12-3P2431T01 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and hygienic zone applications.
