Through-Beam Photoelectric Sensor WSE2S-2P3030S02 | 2.5m Sensing Range | IP67 Rated | Fast Response Time | by SICK
The Through-Beam Photoelectric Sensor WSE2S-2P3030S02 is designed for industrial automation, featuring a sensing range of up to 2.5 meters and a fast response time of under 0.4 ms. With an IP67 rating for dust and water protection, this sensor is perfect for safety and monitoring in manufacturing processes, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 2 m (max 2.5 m)
- Light source: PinPoint LED, wavelength 640 nm
- Switching output: PNP, max output current ≤ 50 mA
- Supply voltage: 10 V DC to 30 V DC
- Response time: < 0.4 ms
- Switching frequency: 1,200 Hz
- Connection: Cable with M8 3-pin connector, 700 mm length
- Housing material: Plastic ABS/PC, Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25 °C to +50 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 21.8mm x 13.5mm x 7.7mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 2.5 meters
- High switching frequency of 1,200 Hz
- IP67 rated for dust and water protection
- Compact rectangular housing design
- Fast response time under 0.4 ms
- PNP switching output with max 50 mA output current
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WSE2S-2P3030S02 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
