Through-Beam Photoelectric Sensor WSE280-2H4331 | 50m Sensing Range | IP66 & IP67 Rated | by SICK
The WSE280-2H4331 Through-beam Photoelectric Sensor is designed for industrial automation, offering a sensing range of up to 50 meters with a visible red light LED. With a robust IP66 and IP67 enclosure rating, it ensures reliable performance in harsh environments. Ideal for object detection and safety monitoring in manufacturing processes, this sensor features a fast response time of ≤ 15 ms and a wide supply voltage range from 24 V to 240 V.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 50 m (max 60 m)
- Light type: Visible red light LED
- Light spot size: Ø 0.6 m at 20 m distance
- Supply voltage: 24 V DC/AC to 240 V DC/AC
- Power consumption sender and receiver: ≤ 3.5 VA each
- Switching output: Relay, electrically isolated, change-over contacts
- Switching current: 3 A at 240 V AC or 30 V DC
- Response time: ≤ 15 ms
- Switching frequency: 33 Hz
- Connection type: Cable gland
- Protection class: II
- Overvoltage category: 2
- Housing material: Plastic ABS, optics material: Plastic PMMA
- Enclosure rating: IP66, IP67
- Ambient operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Dimensions (H x L x W): 75mm x 63mm x 24mm
- Weight: 0.3 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 50 meters, max 60 meters
- Rectangular housing design with LED light source
- Potentiometer adjustment for sensitivity
- Relay switching output with change-over contacts
- High switching frequency of 33 Hz and fast response time ≤ 15 ms
- Robust housing with IP66 and IP67 enclosure rating
- Wide supply voltage range from 24 V DC/AC to 240 V DC/AC
- Mounting bracket BEF-W280 included
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and packaging systems
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with ≤ 3.5 VA power usage
- Durable ABS and PMMA materials for long service life reducing waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK WSE280-2H4331 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
