Through-beam Photoelectric Sensor HSE18L-J4A5BH | 50m Sensing Range | IP67 & IP69K Rated | Fast Response Time | by SICK
The HSE18L-J4A5BH Through-beam Photoelectric Sensor is designed for industrial automation, offering a sensing range of up to 50 meters with a fast response time of ≤ 0.5 ms. With its durable IP67 and IP69K rated housing, this sensor ensures reliable performance in harsh environments, making it ideal for object detection and safety monitoring in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 50 m (max 60 m)
- Light source: Laser, wavelength 655 nm, Laser class 1
- Housing material: Plastic, VISTAL®; Optics material: Plastic, PMMA
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Current consumption: ≤ 20 mA
- Switching output: PNP, dark switching with alarm output
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -30°C to +55°C
- Storage temperature: -40°C to +70°C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 48.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red laser light
- Sensing range up to 50 meters, maximum 60 meters
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy adjustment
- IP67 and IP69K rated for dust and water protection
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Dual PNP switching outputs with dark switching mode
- Operating temperature range from -30°C to +55°C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper alignment and secure mounting using the M18 threaded housing and supplied fastening nut.
Applications
- Industrial automation for object detection
- Small object detection in manufacturing lines
- Safety and monitoring in production processes
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HSE18L-J4A5BH Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
