Through-beam Photoelectric Sensor HSE18L-A1G5AB | 60m Sensing Range | IP67 & IP69K Rated | by SICK
The HSE18L-A1G5AB Through-beam Photoelectric Sensor is designed for industrial automation, offering a remarkable sensing range of up to 60 meters with a visible red laser light. Ideal for precise object detection in manufacturing processes, this sensor features a high switching frequency of 1,000 Hz and robust IP67 and IP69K ratings for protection against dust and water, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 60 m
- Light source: Laser, wavelength 655 nm, Laser class 1
- Switching output: PNP and NPN, dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Enclosure rating: IP67, IP69K
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Cable length: 2 m, PVC cable
- Protection class: III
- Operating temperature: -30°C to +55°C
- Storage temperature: -40°C to +70°C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 46mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red laser light
- Sensing range up to 50 meters
- Hybrid housing design with M18 thread diameter
- Dark switching mode with PNP and NPN outputs
- High switching frequency of 1,000 Hz
- IP67 and IP69K rated for robust protection
- Operating temperature range from -30°C to +55°C
- Cable open end connection with 2 m PVC cable
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Small object detection in manufacturing processes
- Automation systems requiring precise sensing
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable housing materials reduce waste and extend product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK HSE18L-A1G5AB Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
