Through-Beam Photoelectric Sensor WS/WE12L-2P430 | 80m Sensing Range | Visible Red Laser Light | IP67 & IP69K Rated | by SICK
The Through-Beam Photoelectric Sensor WS/WE12L-2P430 is designed for high-speed object detection in industrial automation, featuring a maximum sensing range of 0 m to 80 m and a visible red laser light source with a wavelength of 650 nm. With a robust metal housing and IP67/IP69K protection ratings, this sensor ensures durability and reliability in demanding environments, making it ideal for manufacturing processes and small object detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Through-beam photoelectric sensor, Laser sensor WS/WE12L-2P430, SICK photoelectric sensor, Industrial laser sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 80 m
- Light source: Laser 1), visible red light
- Light spot size: Ø 150 mm at 60 m
- Laser class: 2
- Wavelength: 650 nm
- Adjustment: Potentiometer
- Supply voltage UB: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption sender: ≤ 45 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Digital output type: PNP
- Signal voltage PNP HIGH/LOW: Uv - < 2.9 V, Uv V / 0 V <= 1.5 V
- Output current max: ≤ 100 mA
- Response time: ≤ 200 µs
- Switching frequency: 2,500 Hz
- Output function: Complementary
- Circuit protection: A, C, D
- Housing: Metal
- Front screen: Plastic, PMMA
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP67, IP69K
- Ambient operating temperature: –10 °C to +50 °C
- Ambient storage temperature: –25 °C to +75 °C
- Dimensions (H x L x W): 49mm x 41.5mm x 15mm
- Weight: 0.26 kg
Key Features
- Through-beam photoelectric sensor with a maximum sensing range of 0 m to 80 m
- Visible red laser light source with a wavelength of 650 nm
- Light spot size of Ø 150 mm at 60 m distance
- Potentiometer adjustment for sensitivity
- High switching frequency of 2,500 Hz and response time ≤ 200 µs
- Robust metal housing with IP67 and IP69K protection ratings
- Complementary PNP digital output with max output current ≤ 100 mA
- Includes 2 clamps BEF-KH-W12 with screws
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with laser safety and electrical connections to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- High-speed object detection
- Small object detection in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable metal housing and long mission time of 10 years reduce waste and replacement frequency
- Low power consumption with supply voltage of 10 V DC to 30 V DC
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WS/WE12L-2P430 Through-beam Photoelectric Sensor is available for immediate purchase. Ideal for industrial automation and high-speed object detection applications.
