Through-Beam Photoelectric Sensor GSE2FS-F5111 | IP67 Rated | Fast Response Time | PNP Output | by SICK
The GSE2FS-F5111 Through-beam Photoelectric Sensor is designed for precise object detection in industrial automation. With a fast response time of under 0.625 ms and a sensing range of up to 40 mm, this sensor is perfect for manufacturing process control and quality inspection systems. Its robust IP67 rated housing ensures durability in various environments, making it an ideal choice for material handling and packaging applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP, dark switching mode
- Output current max: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Light source: PinPoint LED, 660 nm wavelength
- Light spot size: Ø 4 mm at 40 mm distance
- Cable: Plastic PVC, Ø 2.3 mm, 200 mm length with M8 3-pin connector
- Housing material: Plastic VISTAL®
- Optics material: Plastic MABS
- Enclosure rating: IP67
- Operating temperature: -20 °C to +50 °C
- Storage temperature: -40 °C to +70 °C
- Repeatability: 0.1 mm
- Dimensions (H x L x W): 21mm x 11mm x 4.5mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Minimum detectable object size of 0.2 mm
- Sensing range up to 40 mm (max 60 mm)
- PinPoint LED light source with 660 nm wavelength
- Rectangular housing design with IP67 enclosure rating
- Dark switching mode with PNP output
- Fast response time under 0.625 ms and switching frequency of 800 Hz
- Cable with M8 3-pin connector, 200 mm length
- Robust plastic housing (VISTAL®) and optics (MABS)
- Wide ambient operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Quality inspection systems
- Material handling and packaging
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption of 20 mA reduces energy usage
- Durable IP67 rated housing extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GSE2FS-F5111 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
