Through-Beam Photoelectric Sensor GSE2FS-N5111 | IP67 Rated | Fast Response Time | NPN Output | by SICK
The GSE2FS-N5111 Through-beam Photoelectric Sensor is designed for precise object detection in industrial automation. With an IP67 rated enclosure, it offers robust protection against dust and water, making it ideal for manufacturing and packaging applications. Featuring a fast response time of under 0.625 ms and a sensing range of up to 40 mm, this sensor ensures reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: 20 mA
- Switching output: NPN
- Switching mode: Light switching
- Max output current: ≤ 50 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection: Cable with M8, 3-pin connector, 200 mm length
- Cable material: Plastic, PVC
- Cable diameter: 2.3 mm
- Circuit protection: Types A, C, D
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, MABS
- Enclosure rating: IP67
- Operating temperature: -20 °C to +50 °C
- Storage temperature: -40 °C to +70 °C
- Repeatability: 0.1 mm
- Light spot size at 40 mm: Ø 4 mm
- Wavelength: 660 nm
- Dimensions (H x L x W): 21mm x 11mm x 4.5mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensing principle
- Rectangular housing design with visible red light
- Minimum detectable object size of 0.2 mm
- Sensing range up to 40 mm
- PinPoint LED light source with 660 nm wavelength
- IP67 rated enclosure for dust and water protection
- Fast response time under 0.625 ms
- NPN switching output with light switching mode
- Cable with M8, 3-pin connector included
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 housing reduces waste from replacements
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GSE2FS-N5111 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and precise object detection applications.
