Through-Beam Photoelectric Sensor GSE2FS-P1151 | IP67 Rated | Fast Response Time | 500 mm Sensing Range | by SICK
The Through-Beam Photoelectric Sensor GSE2FS-P1151 is designed for precise object detection in industrial automation. With a sensing range of up to 500 mm and a fast response time of under 0.625 ms, it’s perfect for manufacturing process control and packaging systems. Its robust IP67-rated housing ensures durability in challenging environments, making it an ideal choice for safety and monitoring applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 mm to 500 mm
- Light source: PinPoint LED, 660 nm wavelength
- Switching output: PNP, light switching mode
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Response time: < 0.625 ms
- Switching frequency: 800 Hz
- Connection type: 3-wire cable, 2 m length, PVC material
- Enclosure rating: IP67
- Operating temperature: -20°C to +50°C
- Housing material: Plastic (VISTAL®)
- Optics material: Plastic (MABS)
- Repeatability: 0.1 mm
- Weight: 40 g
- Dimensions (H x L x W): 21mm x 11mm x 4.5mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Rectangular housing design with IP67 enclosure rating
- Minimum detectable object size of 1 mm
- Sensing range up to 500 mm
- PinPoint LED light source with 660 nm wavelength
- Fast response time under 0.625 ms and switching frequency of 800 Hz
- PNP switching output with light switching mode
- Robust plastic housing (VISTAL®) and optics material (MABS)
- Wide ambient operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in production lines
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable design reduces waste and replacement frequency
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK GSE2FS-P1151 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
