Through-Beam Photoelectric Sensor | Infrared LED | 15m Sensing Range | IP66/IP67/IP69K Rated | by SICK
The Through-Beam Photoelectric Sensor is designed for industrial automation, featuring an infrared LED light source with a sensing range of up to 15 meters. Ideal for hygienic and washdown zones, this sensor boasts a robust metal housing with PTFE coating, ensuring durability in harsh environments. With a high switching frequency of 1,500 Hz and a response time of ≤ 330 µs, it’s perfect for safety and monitoring in manufacturing processes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 15 m (max 20 m)
- Light source: Infrared LED, wavelength 880 nm
- Light spot size at 15 m: Ø 220 mm
- Adjustment: Potentiometer, 5 turns
- Angle of dispersion: Approx. 1.5°
- Supply voltage: 10 V DC to 30 V DC
- Current consumption sender: ≤ 30 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Output type: PNP, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 330 µs
- Switching frequency: 1,500 Hz
- Housing: Metal zinc diecast with PTFE coating
- Connection: Male M12, 4-pin
- Enclosure rating: IP66, IP67, IP69K
- Operating temperature: -40 °C to +60 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 49mm x 42mm x 16mm
- Weight: 0.12 kg
Key Features
- Through-beam photoelectric sensor with infrared LED light source
- Sensing range up to 15 m (max 20 m)
- Teflon coated housing suitable for hygienic and washdown zones
- Potentiometer adjustment with 5 turns
- High switching frequency of 1,500 Hz
- IP66, IP67, and IP69K rated for harsh environments
- Metal zinc diecast housing with PTFE coating
- Complementary PNP output with light/dark switching mode
- Response time ≤ 330 µs
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connections according to manufacturer guidelines.
Applications
- Industrial automation for object detection
- Hygienic and washdown zones requiring robust sensors
- Safety and monitoring in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- Energy-efficient LED light source minimizes power consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WSE12-3P2411T01 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and hygienic zone applications.
