Through-beam Photoelectric Sensor HSE18-P1G1BA | Infrared LED | 15m Sensing Range | IP67 & IP69K Rated | by SICK
The HSE18-P1G1BA Through-beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 15 meters and a robust hybrid housing with IP67 and IP69K ratings. With a fast response time of ≤ 0.5 ms and high switching frequency of 1000 Hz, it ensures reliable object detection and monitoring in manufacturing processes, making it ideal for safety applications in production lines.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 to 15 meters (max 20 meters)
- Light source: Infrared LED, wavelength 850 nm
- Housing design: Hybrid with M18 thread diameter
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP complementary, light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Connection type: 2 m cable, plastic PVC
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40°C to +70°C
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 46mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with infrared LED light source
- Sensing range up to 15 meters, maximum 20 meters
- Hybrid housing design with M18 thread diameter
- Signal strength light bar for easy alignment
- High switching frequency of 1000 Hz and fast response time ≤ 0.5 ms
- Complementary PNP switching outputs with light/dark switching modes
- Robust plastic housing with IP67 and IP69K protection ratings
- Wide ambient operating temperature range from -40°C to +70°C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper alignment and electrical connection according to industrial safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable design reduces waste and replacement frequency
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HSE18-P1G1BA Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control applications.
