Through-Beam Photoelectric Sensor | Infrared LED | 15m Sensing Range | IP67 Rated | by SICK
The ZSE18-4AB4A3 Through-beam Photoelectric Sensor is designed for industrial automation, featuring an infrared LED light source and a sensing range of up to 15 meters. With a robust IP67-rated housing, it ensures reliable performance in harsh environments, making it ideal for manufacturing process control and safety systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dimensions (H x L x W): 44.2mm x 33.3mm x 13.6mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with infrared LED light source
- Sensing range up to 15 meters, maximum 17 meters
- Hybrid housing design with M18 thread diameter for easy mounting
- Push-pull PNP/NPN switching outputs with light and dark switching modes
- High switching frequency of 1,000 kHz and fast response time ≤ 500 µs
- Robust plastic ABS housing with IP67 enclosure rating for harsh environments
- Wide ambient operating temperature range from -40 °C to +55 °C
- Male M12 4-pin connector for reliable electrical connection
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper alignment and electrical connection.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and security systems
- Material handling and packaging
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤ 15 mA current draw
- Durable construction reduces waste and replacement frequency
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK ZSE18-4AB4A3 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control.
