Through-Beam Photoelectric Sensor GSE2FS-E1151 | IP67 Rated | 500mm Sensing Range | NPN Output | by SICK
The GSE2FS-E1151 Through-beam Photoelectric Sensor is designed for precise object detection in industrial automation. With a sensing range of up to 500 mm and a high switching frequency of 800 Hz, it ensures reliable performance in manufacturing and packaging applications. Its IP67 rated enclosure provides excellent dust and water protection, making it ideal for harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 mm to 500 mm
- Light source: PinPoint LED, 660 nm wavelength
- Switching output: NPN, dark switching mode
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Response time: less than 0.625 ms
- Switching frequency: 800 Hz
- Connection type: 3-wire cable, 2 m length, PVC material
- Enclosure rating: IP67
- Operating temperature: -20°C to +50°C
- Repeatability: 0.1 mm
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, MABS
- Dimensions (H x L x W): 21mm x 11mm x 4.5mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Rectangular housing design with PinPoint LED light source
- Minimum detectable object size of 1 mm
- Sensing range up to 500 mm
- Dark switching mode with NPN output
- High switching frequency of 800 Hz
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -20°C to +50°C
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Packaging and material handling systems
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK GSE2FS-E1151 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
