Through-Beam Photoelectric Sensor WSE2S-2N3230 | IP67 Rated | Fast Response Time < 0.4 ms | Sensing Range Up to 2.5m | by SICK
The WSE2S-2N3230 Through-beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 2.5 meters and a fast response time of less than 0.4 ms. With an IP67 rated housing, it withstands harsh environments, making it ideal for manufacturing process control and safety monitoring in production lines.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: NPN, light/dark switching
- Maximum output current: ≤ 50 mA
- Response time: < 0.4 ms
- Switching frequency: 1200 Hz
- Connection: Cable with M8 male connector, 4-pin, 200 mm
- Cable material: Plastic, PVC
- Cable diameter: 3 mm
- Housing material: Plastic ABS/PC
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25°C to +50°C
- Storage temperature: -40°C to +75°C
- Light wavelength: 640 nm
- Light spot size at 1500 mm: Ø 65 mm
- Dimensions (H x L x W): 22mm x 14mm x 8mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensing principle
- Visible red light with PinPoint LED
- Sensing range up to 2.5 meters
- Fast response time under 0.4 ms
- NPN switching output with light/dark switching mode
- Robust IP67 rated housing for harsh environments
- Wide operating temperature range from -25°C to +50°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable design reduces waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WSE2S-2N3230 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control.
