Through-Beam Photoelectric Sensor WSE2S-2E3130 | IP67 Rated | Fast Response Time | NPN Output | by SICK
The WSE2S-2E3130 Through-beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 2.5 meters and a fast response time of under 0.4 ms. With an IP67 enclosure rating and a durable design, this sensor is perfect for object detection and manufacturing process control, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: NPN, dark switching mode
- Output current max: ≤ 50 mA
- Response time: < 0.4 ms
- Switching frequency: 1,200 Hz
- Light source: PinPoint LED, 640 nm wavelength
- Light spot size at 1500 mm: Ø 65 mm
- Connection: Cable with M8 3-pin connector, 200 mm length
- Cable material: Plastic PVC, diameter 3 mm
- Housing material: Plastic ABS/PC
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25 °C to +50 °C
- Storage temperature: -40 °C to +75 °C
- Dimensions (H x L x W): 21.8mm x 13.5mm x 7.7mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 2.5 meters
- PinPoint LED light source with 640 nm wavelength
- Rectangular housing design with IP67 enclosure rating
- Fast response time under 0.4 ms and switching frequency of 1,200 Hz
- NPN dark switching output with max output current ≤ 50 mA
- Cable with M8 3-pin connector, 200 mm length
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with 20 mA current draw
- Durable IP67 rated housing reduces waste by extending product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WSE2S-2E3130 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and manufacturing process control applications.
