Through-beam Photoelectric Sensor WSE2S-2F1330 | IP67 Rated | 1,200 Hz Switching Frequency | 2.5m Sensing Range | by SICK
The WSE2S-2F1330 Through-beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 2.5 meters and a high switching frequency of 1,200 Hz. With an IP67 rated enclosure, it ensures reliable performance in dusty and wet environments, making it ideal for manufacturing process control and safety monitoring in machinery.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP, dark switching
- Maximum output current: ≤ 50 mA
- Response time: < 0.4 ms
- Switching frequency: 1,200 Hz
- Connection: 3-wire cable, 2 m length, PVC material
- Cable diameter: 3 mm
- Housing material: Plastic ABS/PC
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25°C to +50°C
- Storage temperature: -40°C to +75°C
- Light source: PinPoint LED, wavelength 640 nm
- Light spot size at 1500 mm: Ø 65 mm
- MTTFD: 2,659 years
- Dimensions (H x L x W): 21.8mm x 13.5mm x 7.7mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 2.5 meters
- Rectangular housing design with PinPoint LED light source
- High switching frequency of 1,200 Hz
- IP67 rated enclosure for dust and water protection
- Dark switching mode with PNP output
- Robust plastic housing made of ABS/PC and optics of PMMA
- Wide operating temperature range from -25°C to +50°C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in machinery
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption of 20 mA reduces energy usage
- Durable IP67 rated housing extends product life and reduces waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WSE2S-2F1330 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
