Through-Beam Photoelectric Sensor WSE2S-2P1130 | IP67 Rated | 1,200 Hz Switching Frequency | Fast Response Time | by SICK
The WSE2S-2P1130 Through-Beam Photoelectric Sensor is designed for industrial automation, featuring a sensing range of up to 2.5 meters and a high switching frequency of 1,200 Hz. With an IP67 rated housing for dust and water protection, this sensor ensures reliable performance in manufacturing processes and material handling applications. Its fast response time of under 0.4 ms makes it ideal for safety and monitoring tasks.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 20 mA
- Switching output: PNP
- Switching mode: Light/dark switching
- Output current max: ≤ 50 mA
- Response time: < 0.4 ms
- Switching frequency: 1,200 Hz
- Connection type: 4-wire cable, 2 m length
- Cable material: Plastic, PVC
- Cable diameter: Ø 3 mm
- Housing material: Plastic, ABS/PC
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Operating temperature: –25 °C to +50 °C
- Storage temperature: –40 °C to +75 °C
- Light source: PinPoint LED, 640 nm wavelength
- Light spot size: Ø 65 mm at 1,500 mm distance
- Dimensions (H x L x W): 22mm x 14mm x 8mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 2.5 meters
- High switching frequency of 1,200 Hz
- IP67 rated housing for dust and water protection
- Fast response time under 0.4 ms
- PNP switching output with light/dark switching mode
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing processes
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption of 20 mA reduces energy usage
- Durable IP67 housing extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for detailed warranty terms.
Available Now
The SICK WSE2S-2P1130 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
