Through-beam Photoelectric Switch WE24-2V530S01 | Dynamic Heating | IP67 Rated | Glass Front Lens | by SICK
The Through-beam photoelectric switch WE24-2V530S01 features a dynamic heating system to prevent condensation and a durable glass front lens for optimal clarity. With a sensing range of up to 60 m and an IP67 rating, this sensor is perfect for industrial automation, ensuring reliable object detection and safety in manufacturing lines.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Through-beam Photoelectric Switch WE24-2V530S01 | Dynamic Heating | IP67 Rated | Glass Front Lens | by SICK
Brand: SICK
SKU: 2026926
Alternatively Known As: Photoelectric sensor, Through-beam sensor, Optical sensor, Photoelectric switch, Industrial sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range: 0 m to 50 m (max 60 m)
- Focus angle: Approx. 1°
- Light source: LED visible red light
- Light spot size at 50 m: Ø 700 mm
- Supply voltage: 10 V DC to 30 V DC
- Power consumption sender: ≤ 150 mA
- Power consumption receiver: ≤ 140 mA
- Switching output: NPN, PNP selectable
- Switching mode: Light/dark switching selectable
- Output current max: ≤ 100 mA
- Response time: ≤ 500 µs
- Switching frequency: 1,000 Hz
- Angle of reception: Approx. 2.5°
- Connection type: Plug, M12, 5-pin
- Circuit protection: Types A, C, D
- Protection class: II
- Housing material: Metal, zinc diecast
- Optics material: Glass
- Enclosure rating: IP67
- Operating temperature: -40°C to +60°C
- Storage temperature: -40°C to +75°C
- Dimensions (H x L x W): 87.5mm x 65mm x 27mm
- Weight: 0.7 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Dynamic front lens heating to prevent condensation
- Glass front lens for durability and clarity
- Rectangular metal zinc diecast housing
- Selectable switching mode: light/dark and PNP/NPN
- High switching frequency of 1,000 Hz
- IP67 rated enclosure for dust and water protection
- Wide ambient operating temperature range from -40°C to +60°C
- Plug connection type: M12, 5-pin
Professional Installation Requirements
- Installation by a qualified electrician or trained technician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for object detection
- Safety and monitoring in manufacturing lines
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable metal housing reduces replacement frequency
- Long service life reduces electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK Through-beam Photoelectric Switch WE24-2V530S01 is available for immediate purchase, ideal for industrial automation and safety applications.
