Tigo Access Point | 50mm x 100mm x 100mm | Solar Accessory by Solar Outlet
Enhance your solar energy systems with the Tigo Access Point, featuring compact dimensions of 50mm x 100mm x 100mm. Ideal for residential and commercial solar installations, supporting renewable energy usage and reducing carbon footprint.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Tigo Access Point | 50mm x 100mm x 100mm | Solar Accessory by Solar Outlet
Brand: Solar Juice
SKU: 10728
Alternatively Known As: Tigo Access Point, Tigo TAP, Tigo Wireless Accessory, Tigo Communication Module
Technical Specifications
- Wireless communication range: up to 115 meters (line of sight)
- Compatible with Tigo Cloud Connect Advanced (CCA)
- Supports multiple Tigo optimizers
- Power supply: 5V DC (via USB or dedicated power adapter)
- Operating temperature: -20°C to +70°C
- Ingress protection: IP65 (suitable for outdoor use)
- Dimensions (H x L x W): 30mm x 80mm x 80mm
- Weight: 0.3 kg
Key Features
- Enables wireless communication between Tigo optimizers and Cloud Connect Advanced
- Supports real-time module-level monitoring
- Easy integration with existing Tigo systems
- Compact and lightweight design
Professional Installation Requirements
- Installation by a qualified solar technician is recommended to ensure optimal system integration and compliance with Australian standards.
Applications
- Solar PV system monitoring
- Commercial and residential solar installations
- Remote communication for Tigo optimizers and modules
Standards & Compliance
- Complies with AS/NZS 5033 – Installation of Photovoltaic (Solar) Systems
Environmental Benefits
- Enhances solar system efficiency, maximizing renewable energy output
- Supports remote monitoring to quickly identify and resolve issues, reducing downtime and waste
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The TIGO TAP (Tigo Access Point) is available for immediate purchase, ideal for enhancing communication and monitoring in solar PV installations.
