Timer (24-240VAC/DC) for 800, 1700 or 4000 Amp Frame | Multifunction Electronic Relay | DIN Rail Mount | by NHP
The Timer (24-240VAC/DC) is a multifunction electronic time relay designed for 800, 1700, or 4000 amp frames. With 6 timing functions and a range from 0.05 seconds to 100 hours, it’s perfect for industrial control panels and automation systems. Featuring DIN rail mounting and screw terminal connections, this relay ensures secure wiring and easy installation, making it ideal for motor control circuits and electrical timing applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Timer (24-240VAC/DC) for 800, 1700 or 4000 Amp Frame | Multifunction Electronic Relay | DIN Rail Mount | by NHP
Brand: NHP
SKU: 1SVR550029R8100
Alternatively Known As: Multifunction Time Relay, Electronic Timer Relay, CT-MFE Timer, DIN Rail Time Relay
Technical Specifications
- Compatibility: Time Relays
- Terminal Type: Screw Terminals
- Control Voltage: 24-240 V AC/DC
- Current Rating: 4 A
- Mounting Type: DIN Rail Mount
- Primary Type: Time Delay Relays
- Termination: Screw
- Timing Range: 0.05 seconds to 100 hours
- Output: 1 c/o (SPDT) rated at 250 V / 4 A
- Dimensions (H x L x W): 83mm x 26mm x 81mm
- Weight: 0.1 kg
Key Features
- Multifunction electronic time relay with 6 timing functions
- 8 time ranges from 0.05 seconds to 100 hours
- Operates on 24-240 V AC/DC control supply voltage
- 1 c/o (SPDT) output rated at 250 V / 4 A
- Voltage-related (non-floating) triggering control input
- DIN rail mounting for easy installation
- Screw terminal connections for secure wiring
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
- Industrial control panels
- Automation systems
- Electrical timing applications
- Motor control circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient operation reduces power consumption in control circuits
- Durable design minimizes replacement frequency and electronic waste
Warranty Information
Standard manufacturer warranty applies. Please refer to NHP warranty terms for details.
Available Now
The NHP CT-MFE multifunction electronic time relay is available for immediate purchase, ideal for industrial and automation control applications.
