Timer Relay In Line Off Delay 180s | 346-440V AC | DIN Rail Mount by NHP
Timer relay with 180-second off delay and 346-440V AC supply—ideal for industrial automation and commercial HVAC systems. Built for high electrical lifespan with DIN rail mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CA7 Timer In Line Off Delay 180s
Brand: NHP
SKU: CRZA7180
Alternatively Known As: Timer relay, Contactor Timer, Delay Timer
Technical Specifications
- Voltage Type for Actuating: AC
- Rated Control Supply Voltage: 346-440 V at AC 50 Hz
- Number of Outputs: 1 delayed changeover contact
- Type of Electric Connection: Screw connection
- Time Range: 180 s
- Time Setting Accuracy: 5 %
- Power Supply Reset Time: 50 ms
- Power Consumption: 0.5 VA
- Electrical Lifespan of Control Contacts: 200,000 cycles
- Mechanical Lifetime of Control Contacts: 30,000,000 cycles
- Max Shock Acceleration: 50 g
- Max Vibration Acceleration: 4 m/s²
- Max Vibration Frequency Operational: 100 Hz
- Operating Temperature: -25 to 45 °C
- Dimensions (H x L x W): 80mm x 109mm x 22.5mm
- Weight: 0.5 kg
Key Features
- Contactor timer with a delay of 180 seconds.
- Suitable for DIN rail mounting.
- High electrical lifespan of 200,000 cycles.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems requiring timed control
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with relevant Australian standards for electrical devices.
Environmental Benefits
- Energy-efficient design minimizes power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA7 Timer In Line Off Delay 180s is available now for immediate purchase. Ideal for industrial and commercial applications requiring precise timing control.
