Timer Relay On Delay 180s | 346-440V | DIN Rail Mount | Easy Install by NHP
Timer relay with 180-second on delay and 346-440V supply—ideal for industrial automation and HVAC systems. Built for precise timing control, with easy screw connection and DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CA7 Timer In Line On Delay 180s
Brand: NHP
SKU: CRZE7180
Alternatively Known As: Contactor Timer, Timer Relay, Delay Timer
Technical Specifications
- Voltage Type for Actuating: AC
- Rated Control Supply Voltage: 346-440 V
- Number of Outputs: 1 delayed changeover contact
- Power Consumption: 0.5 VA
- Electrical Lifespan of Control Contacts: 200,000 cycles
- Mechanical Lifetime of Control Contacts: 30,000,000 cycles
- Operating Temperature: -25 to 45 °C
- Time Setting Accuracy: 5%
- Power Supply Reset Time: 50 ms
- Max Shock Acceleration: 50 g
- Max Vibration Acceleration: 4 m/s²
- Max Vibration Frequency Operational: 100 Hz
- Dimensions (H x L x W): 80mm x 109mm x 22.5mm
- Weight: 0.5 kg
Key Features
- Delay on energization function with a time range of 180 seconds.
- Screw connection for easy installation.
- Suitable for DIN rail mounting.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems requiring timed control
- Commercial: HVAC systems for delay functions
- General: Any application needing a delay on energization
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA7 Timer In Line On Delay 180s is available now for immediate purchase. Ideal for industrial and commercial applications requiring precise timing control.
Non-Returnable & Non-Cancellable
