Trip Unit NSX100 AC 3P3D 100A TMD | Thermal-Magnetic Protection | 3-Pole Configuration | by Clipsal
The Trip Unit NSX100 AC 3P3D 100A TMD is a thermal-magnetic trip unit designed for ComPacT NSX100/160/250 circuit breakers, providing reliable 3-pole protection. With adjustable thermal and magnetic settings, it’s perfect for industrial and commercial electrical distribution panels, ensuring safety and efficiency in low voltage circuits.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Trip Unit NSX100 AC 3P3D 100A TMD | Thermal-Magnetic Protection | 3-Pole Configuration | by Clipsal
Brand: Clipsal
SKU: SCHC103TM100
Alternatively Known As: NSX100 Trip Unit, 100A Thermal Magnetic Trip Unit, ComPacT NSX100 3P3D TMD, SCHC103TM100, Schneider NSX100 Trip Unit
Technical Specifications
- Type: Thermal-magnetic trip unit
- Rated current: 100A
- Number of poles: 3
- Protection: 3D (3-pole protection)
- Compatibility: ComPacT NSX100/160/250 circuit breakers
- Adjustable thermal and magnetic settings
- Operating voltage: 690V AC max
- Frequency: 50/60Hz
- Dimensions (H x L x W): 130mm x 60mm x 75mm
- Weight: 0.8 kg
Key Features
- Thermal-magnetic trip unit for ComPacT NSX100/160/250 circuit breakers
- 3 pole, 3D (3-pole protection) configuration
- 100A rated current for reliable circuit protection
- Adjustable thermal and magnetic protection settings
- Robust design for demanding industrial and commercial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Industrial electrical distribution panels
- Commercial switchboards
- Protection of low voltage circuits in buildings
- Upgrading or retrofitting circuit breakers in existing installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Supports efficient energy management by preventing overloads and short circuits
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Trip Unit NSX100 AC 3P3D 100A TMD (SCHC103TM100) is available for immediate purchase. Ideal for industrial and commercial electrical protection applications.
