TRON Fast Acting Fuse | 350A Amperage Rating | Class T Fuse | High Interrupt Rating | @Each by Eaton
The TRON Fast Acting Fuse is designed for reliable circuit protection with a 350A amperage rating and high interrupt ratings of 20 kAIC at 160 Vdc and 200 kAIC at 300 Vac. Ideal for VFD line protection and industrial electrical circuits, this Class T fuse ensures enhanced safety and compliance with AS/NZS 3000 standards. Its bolted blade end connection type makes installation straightforward for qualified electricians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TRON Fast Acting Fuse | 350A Amperage Rating | Class T Fuse | High Interrupt Rating | @Each by Eaton
Brand: Eaton
SKU: JJN-350
Alternatively Known As: JJN-350 Fuse, Eaton Class T Fuse, Fast Acting Fuse 350A, TRON JJN Fuse
Technical Specifications
- Amperage Rating: 350 A
- Voltage Rating: 300 Vac, 160 Vdc
- Interrupt Rating: 20 kAIC at 160 Vdc, 200 kAIC at 300 Vac
- Fuse Class: Class T
- Connection Type: Bolted blade end x bolted blade end
- Fuse Indicator: Non-indicating
- Dimensions (H x L x W): 25mm x 70mm x 25mm
- Weight: 0.11 kg
Key Features
- Current-limiting fuse for enhanced circuit protection
- Bolted blade end x bolted blade end connection
- Non-indicating fuse type
- High interrupt rating: 20 kAIC at 160 Vdc, 200 kAIC at 300 Vac
- Class T fuse for fast acting protection
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper fuse application.
Applications
- VFD line protection
- Current-limiting applications
- Industrial electrical circuits requiring Class T fuses
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- CE marked for safety and environmental standards
Warranty Information
Not applicable
Available Now
The Eaton TRON Fast Acting Fuse JJN-350 is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
