TVS Thermal Overload Relay 7...10A | Adjustable Current Range | Manual & Automatic Reset | Phase Failure Sensitivity | @Pack of 1 | by Clipsal
The TVS Thermal Overload Relay 7...10A is designed for reliable motor protection in industrial automation. With an adjustable current range of 7 to 10A and both manual and automatic reset options, it ensures fast response to overloads and phase loss. Ideal for control panels, HVAC systems, and pumps, this relay enhances energy efficiency and extends equipment lifespan.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TVS Thermal Overload Relay 7...10A | Adjustable Current Range | Manual & Automatic Reset | Phase Failure Sensitivity | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLRE14
Alternatively Known As: Thermal Overload Relay, Motor Overload Protector, Overload Protection Relay, SCHLRE14 Relay, Clipsal Overload Relay
Technical Specifications
- Current adjustment range: 7...10A
- Trip class: 10A
- Reset: Manual/Automatic
- Phase failure sensitivity: Yes
- Mounting: Direct to contactor
- Auxiliary contacts: 1 NO + 1 NC
- Operating temperature: -20°C to +60°C
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 70mm x 75mm x 45mm
- Weight: 0.18 kg
Key Features
- Adjustable current range: 7 to 10A
- Manual and automatic reset options
- Trip class 10A for fast motor protection
- Phase failure sensitivity
- Direct mounting to contactors
- Reliable protection against overloads and phase loss
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure correct integration with motor starters and compliance with safety standards.
Applications
- Motor protection in industrial automation
- Control panels for machinery
- HVAC systems
- Pumps and compressors
- Conveyor systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Prevents motor damage, reducing equipment waste
- Enhances energy efficiency by protecting motors from overload
- Supports longer equipment lifespan, minimizing resource consumption
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal TVS Thermal Overload Relay 7-10A (SCHLRE14) is available for immediate purchase. Ideal for industrial motor protection and automation panels.
