Twin Core Electrical Cable | 1.5mm Copper Conductor | 450/750V PVC Insulation | Easy-Peel Sheath | by Electra Cables
The Twin Core Electrical Cable features a 1.5mm plain annealed copper conductor and is insulated with durable PVC, rated for 450/750V. Ideal for domestic, commercial, and industrial wiring applications, this cable is designed for easy installation with its easy-peel sheath, ensuring safety and compliance with Australian standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Twin Core Electrical Cable, 1.5mm Twin Active Cable, V90HT PVC Sheathed Cable, Red White Core Cable
Technical Specifications
- Conductor: Plain annealed copper (AS/NZS 1125)
- Insulation: PVC V90
- Sheath: 3V-90 Easytear White
- Voltage Rating: 450/750V
- Number of Cores: 2
- Core Size: 1.5mm
- Operating Temperature: 90°C
- Standard: AS/NZS 5000.2
- Length: 100 meters per roll
- Dimensions (H x L x W): 10mm x 100000mm x 10mm
- Weight: 2.5 kg
Key Features
- 1.5mm twin active cable with 2 cores
- 450/750V V-90 insulated with PVC sheath
- Easy-peel sheath for general wiring
- Plain annealed copper conductor compliant with AS/NZS 1125
- Normal operating temperature of 90 degrees Celsius
- Insulation and sheath designed for durability and safety
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with local electrical codes and safety standards.
Applications
- Domestic wiring
- Commercial wiring
- Industrial wiring
- Unenclosed installations
- Closed conduit installations
- Buried direct or underground ducts where not subject to mechanical damage
Standards & Compliance
- AS/NZS 5000.2 – Electrical cables – Polyvinyl chloride (PVC) insulated cables of rated voltages up to and including 450/750 V
Environmental Benefits
- Durable PVC insulation reduces need for frequent replacements
- Compliant with Australian standards ensuring safety and reduced environmental impact
Warranty Information
Standard manufacturer warranty applies. Please refer to Electra Cables for detailed warranty terms.
Available Now
Available for immediate purchase, ideal for domestic, commercial, and industrial electrical wiring applications.
