Twin-Stick Safety Light Curtain | 14 mm Resolution | 0 m to 8 m Scanning Range | 480 mm Protective Field Height | by SICK
The Twin-Stick Safety Light Curtain is designed for industrial safety monitoring, featuring a 14 mm resolution and a scanning range of up to 8 m. With a protective field height of 480 mm and a fast response time of ≤ 14 ms, it’s perfect for automation and manufacturing safety systems, ensuring reliable presence detection and compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- System part: 1 Twin-Stick
- Resolution: 14 mm
- Scanning range: Minimum 0 m to 6 m, Typical 0 m to 8 m
- Protective field height: 480 mm
- Response time: ≤ 14 ms
- Synchronization: Optical, no separate synchronization needed
- Safety type: Type 2 (IEC 61496-1)
- Safety integrity level: SIL 1 (IEC 61508)
- Category: Category 2 (EN ISO 13849)
- Test rate: 58/s
- Performance level: PL c (EN ISO 13849)
- Output type: PNP semiconductors, short-circuit protected, cross-circuit monitored
- ON state voltage: 24 V DC (VS – 2.25 V DC ... VS)
- OFF state voltage: ≤ 2 V DC
- Current capacity per OSSD: ≤ 300 mA
- Supply voltage: 24 V DC (19.2 V DC ... 28.8 V DC)
- Power consumption: ≤ 3 A
- Housing material: Aluminum alloy ALMGSI 0.5
- Protection class: III (EN 61140)
- Enclosure rating: IP65 (EN 60529)
- Operating temperature: –20 °C to +55 °C
- Storage temperature: –25 °C to +70 °C
- Vibration resistance: 5 to 150 Hz, 3.5 mm / 1 g
- Shock resistance: 15 g / 6 ms
- Cable length: 350 mm
- Permitted cable length: ≤ 20 m
- Wave length: 850 nm
- Dimensions (H x L x W): 480mm x 32mm x 15mm
- Weight: 0.175 kg
Key Features
- Twin-Stick system part for miniTwin2 standalone use
- O-fix bracket mounting system
- 14 mm resolution with scanning range 0 m to 8 m typical
- Protective field height of 480 mm
- Response time ≤ 14 ms
- Optical synchronization without separate synchronization
- Restart interlock and external device monitoring (EDM)
- Automatic beam coding
- LED display elements for status indication
- Short-circuit protected PNP semiconductor output signal switching devices (OSSDs)
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure compliance with safety standards and proper system integration.
Applications
- Industrial safety monitoring for machinery
- Standalone device for presence detection
- Automation and manufacturing safety systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with ≤ 3 A current draw
- Durable aluminum alloy housing for long product life
- Complies with RoHS for reduced hazardous substances
Warranty Information
Warranty details available upon request from manufacturer.
Available Now
The SICK C2MT-04814BBC03DB0 Twin-Stick Safety Light Curtain is available for immediate purchase, ideal for industrial safety and automation applications.
