Ultrasonic Fork Sensor UFS3-37N415 | IP65 Rated | NPN Output | Adjustable Teach-in Modes | by SICK
The Ultrasonic Fork Sensor UFS3-37N415 is designed for reliable label detection and object sensing in industrial automation. With an IP65 rated enclosure, it offers protection against dust and water, making it ideal for harsh environments. Featuring adjustable sensitivity via Teach-in modes and a fast IO-Link V1.1 interface, this sensor ensures efficient operation and precise detection for manufacturing and packaging applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 50 mA
- Switching frequency: 1.1 kHz
- Response time: ≤ 440 µs
- Jitter: 40 µs
- Switching output: NPN, max output current 100 mA
- Adjustment: Plus/minus button, cable Teach-in (sensitivity, light/dark switching, dynamic)
- Teach-in modes: 1-point, 2-point, dynamic
- IO-Link: V1.1, COM3 (230.4 kBaud), cycle time 4 ms
- Enclosure rating: IP65
- Housing material: Zamak and glass fiber reinforced plastic
- Connection type: Male M8, 4-pin connector
- Operating temperature: +5 °C to +55 °C
- Storage temperature: -20 °C to +70 °C
- Protection class: III
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Dimensions (H x L x W): 37mm x 70mm x 20mm
- Weight: 0.1 kg
Key Features
- Ultrasonic detection principle for reliable sensing
- Fork shaped housing design with 2.6 mm fork width
- Label detection capability with minimum detectable object size of 2 mm
- Adjustable via plus/minus button and cable with Teach-in modes
- IO-Link V1.1 interface with fast data transmission and cycle time
- NPN switching output with light/dark switching mode
- IP65 rated enclosure for protection against dust and water
- LED indicators for power and switching output status
- Reverse polarity and short-circuit protected circuitry
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and configuration.
Applications
- Industrial automation for label detection
- Object detection in manufacturing processes
- Packaging and material handling systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation reduces power consumption in industrial settings
- Durable IP65 housing extends product life, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK UFS3-37N415 Ultrasonic Fork Sensor is available for immediate purchase, ideal for industrial automation and label detection applications.
