Ultrasonic Fork Sensor UFS3-37N515 | IP65 Rated | 2.6mm Fork Width | NPN Output | by SICK
The Ultrasonic Fork Sensor UFS3-37N515 is designed for precise label detection in industrial automation. With an IP65 rated enclosure, it ensures reliable performance in challenging environments. Featuring a 2.6mm fork width and NPN switching output, this sensor is perfect for manufacturing processes and packaging systems, providing quick response times and energy-efficient operation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 50 mA
- Switching frequency: 1.1 kHz
- Response time: ≤ 440 µs
- Switching output: NPN, max output current 100 mA
- Teach-in modes: 1-point, 2-point, dynamic
- IO-Link V1.1 with COM3 data transmission rate (230.4 kBaud)
- Cycle time: 4 ms
- Enclosure rating: IP65
- Operating temperature: +5 °C to +55 °C
- Storage temperature: -20 °C to +70 °C
- Housing material: Zamak and glass fiber reinforced plastic
- Cable: PVC, 0.31 m length with M12 4-pin connector
- Dimensions (H x L x W): 37mm x 70mm x 20mm
- Weight: 0.1 kg
Key Features
- Ultrasonic detection principle for reliable sensing
- Fork shaped housing design with 2.6 mm fork width
- Minimum detectable object size: 2 mm label size with 1 mm label gap
- Adjustable via plus/minus button and cable with Teach-in modes
- IO-Link V1.1 communication with 4 ms cycle time
- NPN switching output with light/dark switching mode
- IP65 rated enclosure for protection against dust and water
- LED indicators for power and switching output status
- Cable with M12 male connector, 4-pin, 0.31 m length
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor calibration.
Applications
- Industrial automation for label detection
- Object detection in manufacturing processes
- Packaging and material handling systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient operation reduces power consumption in industrial applications
- Durable IP65 housing minimizes waste by extending product lifespan
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK UFS3-37N515 Ultrasonic Fork Sensor is available for immediate purchase, ideal for industrial automation and label detection applications.
